HALLIDAY + BAILLIE KEY SLIDING DOOR LOCK SYSTEM - HB630 SERIES
Halliday + Baillie Key Lock Sliding System with 55mm backset can be used on either internal or external doors. The HB630 Series has several configurations, to suit door usage. Cylinders are ordered separately with confirmation of the door thickness.
Please note that the “HB630 Series” denotes the type of lock body used with various flush pull configurations. The “HB630” set has a key and snib both sides, and is one possible configuration in the series.
System Configuration Options:
HB 630 – Key and Snib Both Sides
HB 632 – Key Snib one side, Blank Outside
HB 633 – Key Snib one side, No Pull Outside
Material: Diecast zinc with brass and 316 stainless steel
Backset : 55mm
Minimum door thickness : 38mm
Flush pulls : 250mm x 36mm x 13mm.
Internal grip depth: 11mm
Click HERE for HB630 technical downloads.
Suitable for timber* or wide profile aluminum doors.
*Please Order with timber fixing kit HERE for timber doors.
Rebate Kit for HB630 series available, click HERE.
Finishes Available:
Satin Chrome, Polished Chrome, Brushed Nickel, Polished Brass, Electro Black Ace, Electro Medium Bronze, Electro Dark Bronze, Appliance White, Dark Bronze, Black Chrome, Electro Flat White
For more information on the finishes click HERE.
Please note only the finishes listed on this page are available for purchase.
Standard HB 630 set includes :
 HB 630 Series Lock Body
 Two HB668 Flush Pulls
 HB 604 Fixing Kits (one set for HB 633)
 Strike and Dust Box - Standard
 Two spindle lengths (please specify door thickness for doors over 50mm)
 Fasteners
 Cylinder ordered separately for slider thickness
This item is special order only, please allow 15-20 working days for dispatch.
