Specifications

Material:

• #304 Stainless Steel
• Nylon Inserts
• Stainless Steel Snap-on Covers

Finish:

• Satin Stainless Steel

Mounting:

• Screw Fix or Bolt Through

Minimum Hinge Clearance For Lift Off Hinges:

• 35mm

Specify:

• 207C_LHHC_SS: Left Hand, Hold Closed. Assists door to move towards Hold Closed position
• 207C_LHHO_SS: Left Hand, Hold Open. Assists door to move towards Hold Open position
• 207C_RHHC_SS: Right Hand, Hold Closed. Assists door to move towards Hold Closed position
• 207C_RHHO_SS: Right Hand, Hold Open. Assists door to move towards Hold Open position

Features:

• Gravity assisted door opening with lift off capability.

Load Rating:

• 15Kg per hinge

For optimum performance:

• 2 hinges per door up to 30Kgs
• For doors over 30Kg allow for 15Kg per hinge

Note: 3 Hinges per door is recommended to prevent door bowing

Note

For Bolt Through use 106C_FACEPLATE Concealed Fix Face Plate (Available in Satin Chrome Plate, Bright Chrome Plate and Satin Nickel Plate)

Note: All Hinges Are Available With Or Without Fixings. Please Nominate Your Requirements At The Time Of Ordering.

Disclaimer

Gravity hinges contain no mechanical components. The functionality of these hinges can vary depending on the environment.
When selecting this product, please view our Product Disclosure Statement in the Care and Maintenance Download below.
