Heavy Duty Fast Fix Hinge with face fix flanges to suit commercial timber / aluminum door applications.

Installation Guide

• Minimum door thickness 40mm
• Up to 2100 high x 900 wide x 80kg - 3 Hinges
• Up to 2400 high x 900 wide x 80kg- 4 Hinges

Fixing

• Heavy duty bi-directional fixing
• Integrated locator step aids in alignment and installation
• Supplied with:
  7 of 10G x 12mm, 304SS undercut countersunk self tapping (AB) Phillip drive screws
  3 of 10G x 32mm, 304SS undercut countersunk self tapping (AB) Phillip drive screws

Technical Specification

• Hinge: 6063-T6 alloy
• Hinge Pin: 6mm 304 grade Stainless Steel
• Nylon bushes
• Squareline heavy duty knuckles
• Interference pressed fit aluminium end caps
